Product Description:
Universal grade, also known as hard glue or transparent benzene, is characterized by its transparency, clarity, and ease of processing. On the other hand, high impact resistance, also known as modified benzene, appears white and opaque. Our distinguishing features include low GEL and low residue.
At our factory, we adhere to strict environmental standards in our production equipment. Our mature and stable production technology is free from any concerns of environmental pollution.
Features:
Injection molding is a manufacturing process in which a material is heated and then injected into a mold cavity under high pressure. The material cools and solidifies to form the desired shape. This process is widely used in the production of various products, including plastic parts, automotive components, and medical devices.
Injection molding offers several advantages, such as the ability to produce complex shapes, high production rates, and the use of a wide range of materials. It is a cost-effective method for mass production and can be highly automated for efficiency. However, tooling costs can be high initially, and design considerations are important to ensure successful molding.
Technical Parameters:
| Property |
Test Method |
Test Condition |
Unit |
General Purpose PS |
| GP5250/N |
GP535N |
GP535H |
GP550N |
GP560N |
| Melt Flow Index |
ASTM D-1238 |
200 °C X 5kg |
g/10 min |
9.0 |
3.5 |
2.6 |
1.9 |
1.9 |
| ISO 1133 |
| Izod Impact Strength |
ASTM D-256 |
23 °C , 6.4mm Thick,Notched |
kg-cm/cm |
1.7 |
1.9 |
2.0 |
1.9 |
1.9 |
| ISO 180 |
23 °C , 4mm Thick,Notched |
kJ/m2 |
1.8 |
1.8 |
1.9 |
1.7 |
1.7 |
Charpy Impact
Strength |
ISO-179 |
23 °C,4mm Thick GPPS Unnotched ,
4mm Thick,HIPS Notched |
kJ/m2 |
8.0 |
8.5 |
7.5 |
8.0 |
8.0 |
| Tensile Strength |
ASTM D-638 |
23 °C , 5mm/min |
kg/cm2 |
440 |
470 |
520 |
510 |
510 |
| ISO 527 |
23 °C , 20mm/min |
MPa |
45 |
45 |
45 |
50 |
50 |
| Tensile Modulus |
ASTM D-638 |
23 °C , 1mm/min |
kg/cm2 |
26500 |
27000 |
27000 |
27000 |
27000 |
| ISO 527 |
23 °C , 1mm/min |
MPa |
3300 |
3350 |
3350 |
3400 |
3400 |
| Tensile Elongation |
ASTM D-638 |
23 °C , 5mm/min |
% |
2 |
2 |
2 |
2 |
2 |
| ISO 527 |
23 °C , 20mm/min |
1.5 |
1.7 |
1.7 |
1.7 |
1.7 |
| Flexural Strength |
ASTM D-790 |
23 °C , 1,2mm/min Span 50.8mm |
kg/cm2 |
900 |
970 |
990 |
1000 |
1000 |
| ISO 178 |
23 °C , 2mm/min Span 64mm |
MPa |
70 |
70 |
80 |
95 |
95 |
| Flexural Modulus |
ASTM D-790 |
23 °C , 1.2mm/min Span 50.8mm |
kg/cm2 |
30000 |
29000 |
30000 |
30000 |
30000 |
| ISO 178 |
23 °C , 2mm/min Span 64mm |
MPa |
3000 |
3100 |
3100 |
3300 |
3300 |
Heat Deflection
Temperature |
ASTM D-648 |
Unannealed, 120°C /h,1.8MPa, 3.2mm Thick |
°C |
75 |
77 |
82 |
82 |
82 |
Annealed 80°C *2hr, 120°C /h,
1.8MPa, 3.2mm Thick |
90 |
92 |
95 |
95 |
95 |
| ISO 75/A |
Unannealed, 120°C /h,
1.8MPa 4mm Thick |
75 |
78 |
82 |
82 |
82 |
Annealed 80°C *2hr, 120°C /h,
1.8MPa 4mm Thick |
90 |
93 |
96 |
96 |
96 |
| Vicat Softening Point |
ASTM D-1525 |
Annealed 80°C *2hr,
10N 50°C /h |
°C |
97 |
99 |
106 |
106 |
106 |
| ISO 306 |
| Residual Monomer |
— |
— |
ppm max |
500 |
500 |
500 |
500 |
500 |
| Flammability |
UL-94 |
— |
— |
1.5mm HB All Color |
1.5mm HB All Color |
1.5mm HB All Color |
1.5mm HB All Color |
1.5mm HB All Color |
| Speciality |
Injection molding |
High heat resistance |
High heat resistance |
High M.W., Extrusion |
High M.W., Extrusion |
| Application |
Food containers, Stationery, Toys, Cassettes, Cosmetic cases |
Tableware, Lampshades, Crystal plates,Toys, Refrigerator drawer |
Refrigerator drawer |
TV & illumination diffusion plate,Light guide plate |
Applications:
Food containers, stationery, toys, cassettes, and cosmetic cases are all items commonly used in daily life. Food containers are essential for storing and transporting food, while stationery is necessary for office or school work. Toys provide entertainment for people of all ages, and cassettes are a nostalgic form of audio recording. Cosmetic cases are used to store and organize makeup and beauty products. Each of these items serves a specific purpose and contributes to the convenience and organization of everyday tasks.
FAQ:
Q: What is the brand name of this product?
A: The brand name is TAIRILAC GPPS.
Q: What is the model number of this GPPS product?
A: The model number is GP5250/N.
Q: What certifications does this product have?
A: This product is certified with ISO 9001/14001.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity is 1 ton.
Q: What is the price range for this GPPS product?
A: The price ranges from 1300 to 1450 USD per ton.
Q: What are the packaging details for this product?
A: The packaging details include 800kg packages.
Q: What is the estimated delivery time for this product?
A: The delivery time is between 30 to 45 days.
Q: What are the payment terms for purchasing this product?
A: The payment terms are TT (Telegraphic Transfer).
