Product Description:
Polystyrene at a general level can serve a variety of purposes in daily life, including the manufacturing of electrical components, instrument shells, toys, lamps and lanterns, household appliances, stationery items, cosmetic containers, indoor and outdoor decorations, fruit trays, and optical components such as prisms, lenses, lens windows, glass moldings, and headlights.
Furthermore, polystyrene is also used in the production of telecom accessories, electrical frequency capacitor films, high-frequency insulation materials for containers, TV guides, chemical containers, among others.
Features:
HP8250, HP825N, HP9450 contain 5-15% rubber components, with impact strength 4-7 times higher than GPPS and significantly improved toughness, but lower than ABS plastic
Good processing and forming fluidity, strong coloring power, suitable for complex structural components; Transmittance of 92%, better than ABS (85%)Its heat resistance upper limit is 90 ℃, which is 30 ℃ lower than ABS, and there is a higher risk of deformation in high-temperature environments.Excellent moisture resistance and insulation, but similar to GPPS in solvent resistance.
Technical Parameters:
| Property |
Test Method |
Test Condition |
Unit |
High Impact PS |
| HP8250 |
HP825N |
HP9450 |
| Melt Flow Index |
ASTM D-1238 |
200 °C X 5kg |
g/10 min |
5.5 |
5.5 |
3.0 |
| ISO 1133 |
| Izod Impact Strength |
ASTM D-256 |
23 °C , 6.4mm Thick,Notched |
kg-cm/cm |
13.0 |
16.0 |
16.0 |
| ISO 180 |
23 °C , 4mm Thick,Notched |
kJ/m2 |
11.0 |
13.0 |
12.0 |
Charpy Impact
Strength |
ISO-179 |
23 °C,4mm Thick GPPS Unnotched ,
4mm Thick,HIPS Notched |
kJ/m2 |
10.0 |
12.5 |
11.5 |
| Tensile Strength |
ASTM D-638 |
23 °C , 5mm/min |
kg/cm2 |
245 |
230 |
240 |
| ISO 527 |
23 °C , 20mm/min |
MPa |
25 |
25 |
25 |
| Tensile Modulus |
ASTM D-638 |
23 °C , 1mm/min |
kg/cm2 |
19000 |
18000 |
18000 |
| ISO 527 |
23 °C , 1mm/min |
MPa |
2200 |
2200 |
2250 |
| Tensile Elongation |
ASTM D-638 |
23 °C , 5mm/min |
% |
55 |
55.0 |
55 |
| ISO 527 |
23 °C , 20mm/min |
55 |
55 |
55 |
| Flexural Strength |
ASTM D-790 |
23 °C , 1,2mm/min Span 50.8mm |
kg/cm2 |
450 |
420 |
440 |
| ISO 178 |
23 °C , 2mm/min Span 64mm |
MPa |
44 |
42 |
47 |
| Flexural Modulus |
ASTM D-790 |
23 °C , 1.2mm/min Span 50.8mm |
kg/cm2 |
20000 |
19000 |
19000 |
| ISO 178 |
23 °C , 2mm/min Span 64mm |
MPa |
2100 |
2100 |
2100 |
Heat Deflection
Temperature |
ASTM D-648 |
Unannealed, 120°C /h,1.8MPa, 3.2mm Thick |
°C |
76 |
73 |
76 |
Annealed 80°C *2hr, 120°C /h,
1.8MPa, 3.2mm Thick |
90 |
89 |
90 |
| ISO 75/A |
Unannealed, 120°C /h,
1.8MPa 4mm Thick |
73 |
71 |
74 |
Annealed 80°C *2hr, 120°C /h,
1.8MPa 4mm Thick |
91 |
89 |
91 |
| Vicat Softening Point |
ASTM D-1525 |
Annealed 80°C *2hr,
10N 50°C /h |
°C |
98 |
97 |
100 |
| ISO 306 |
| Residual Monomer |
— |
— |
ppm max |
500 |
500 |
500 |
| Flammability |
UL-94 |
— |
— |
1.5mm HB All Color |
1.5mm HB All Color |
1.5mm HB All Color |
| Speciality |
High Impact, Normal flow |
Super-high Impact |
| Application |
Electrical appliance housing, Terminal housing,Panel of computer host |
line wheel, Panel of
washing machine,
Electronic carrier tapes |
Applications:
Electrical appliance housing refers to the protective casing that encloses electronic components, such as wiring and circuit boards, in devices like televisions, refrigerators, and microwaves.
Terminal housing is an enclosure that contains connection points for electrical wires or cables to connect various components or devices together, ensuring proper functioning and organization within a system.
A panel of a computer host typically serves as the front-facing interface where users can interact with the computer, containing components such as power buttons, USB ports, audio jacks, and indicator lights for user convenience and system status monitoring.
FAQ:
Q: What is the model number of the High Impact Polystyrene product?
A: The model number of the product is GP525.
Q: What is the minimum order quantity for the High Impact Polystyrene?
A: The minimum order quantity ranges from 800 to 1200 kilograms.
Q: What is the price range for the High Impact Polystyrene product?
A: The price ranges from 1300 to 1500 USD.
Q: How is the High Impact Polystyrene product packaged?
A: The product is packaged in bags.
Q: What are the payment terms for purchasing the High Impact Polystyrene?
A: The payment terms are TT (Telegraphic Transfer).
